Sanitary Type
Front flush diaphragm pressure transducer have been specifically designed for the measurement of viscous, paste-like, crystallizing, or solids-containing media, which could clog the pressure channel of conventional process connections. Use our 316L stainless steel sanitary flush membrane pressure sensor, it does not have dead space and is especially easy to clean. Low-maintenance and trouble-free pressure measurement. With cooling fins can realize it to be a 150℃ high temperature hygienic pressure transmitter.
Sales contact
Pokcenser Automation Technology Co., Ltd
Mobile: +86 181 7515 5326
Email: info@pokcenser.com
Tel: +86-731-8229 9492
PWP411 Sanitary Pressure Sensor with Flush Diaphragm
Features
- Flush design prevents clogging
- Sanitary or Clean-in Place applications
- Widetemperature range -40…+150℃
- Measuring range up to 7MPa(Customizable)
- Process connection in high-end stainless steel G1/2” or Tri-clamp 1-1/2”
Application:
- Food, dairy and beverage processing
- Filling and packing machinery
- Cleaning systems
- Hydraulic fluids
- Waste water treatment
- Level measurement
- Dosing of glues, adhesives, foams and other viscous media
Advantages
- Food graded
- Capable in high temperature application
- Free of dead space and easy to clean
- Media changeable
This food grade pressure sensor is a flush diaphragm type pressure transmitter. With an integrated cooling element it can work in high medium temperatures up to 150℃. Low-maintenance and trouble-free hygienic pressure level transmitter is thus also guaranteed in critical applications with frequently changing media.
Technical Parameters
| Model | PWP411 |
| Pressure Type | Relative (gauge) /Absolute pressure/Sealed gauge pressure |
| Pressure Range | -0.1MPa … 0kPa~10kPa …7MPa |
| Safe Overload | ≤200%FS |
| Electrical Connection | DIN43650 Hirschmann Connector/M12*4pins/Directly outlet cable |
| Accuracy | ±0.5%FS(Typical), ±0.25%FS, ±0.1%FS optional |
| Signal Output | 4-20mA/0.5-4.5V/0-5V/0-10V/I2C/RS485 |
| Power Supply | 3.3VDC/5VDC/8-24VDC/10-30VDC/12-30VDC/15-30VDC |
| Response Time | ≤3ms |
| Long-term Stability (%FS/year) | ≤0.5 for 0.5%FS accuracy |
| Compensation Temp. | 0℃~+50℃(≤200kPa), -10℃~+60℃(>200kPa) |
| Working Temp. | -20℃~+85℃(Typical); -20℃~+150℃(With cooling element) |
| Storage Temp. | -40℃~+85℃ |
| IP Rating | IP65/IP67 |
| Process Connection | G1/2” male, G1” male, M20 x 1.5 male |
